UB 920x420x449
Universal Beams
refer to : EN 10365:2017
a European standard that defines the dimensions, tolerances, and sectional properties for hot-rolled steel channels, I-beams, and H-beams used in construction and engineering. It ensures uniformity and compatibility across European structural steel products.
Dimension : 948x423x24x42.7
Depth : 948 mm
Width : 423 mm
Web Thickness : 24 mm
Flange Thickness : 42.7 mm
Root Fillet Radius : 19 mm
Sectional Area : 571.4 cm2
Unit Weight : 448.5 kg/m
