UB 914x305x289
Universal Beams
refer to : EN 10365:2017
a European standard that defines the dimensions, tolerances, and sectional properties for hot-rolled steel channels, I-beams, and H-beams used in construction and engineering. It ensures uniformity and compatibility across European structural steel products.
Dimension : 926.6×307.7×19.5×32
Depth : 926.6 mm
Width : 307.7 mm
Web Thickness : 19.5 mm
Flange Thickness : 32 mm
Root Fillet Radius : 19 mm
Sectional Area : 368.3 cm2
Unit Weight : 289.1 kg/m
UB 914x305x289
