UB 920x420x390
Universal Beams
refer to : EN 10365:2017
a European standard that defines the dimensions, tolerances, and sectional properties for hot-rolled steel channels, I-beams, and H-beams used in construction and engineering. It ensures uniformity and compatibility across European structural steel products.
Dimension : 936x420x21.3×36.6
Depth : 936 mm
Width : 420 mm
Web Thickness : 21.3 mm
Flange Thickness : 36.6 mm
Root Fillet Radius : 19 mm
Sectional Area : 494.3 cm2
Unit Weight : 388 kg/m
UB 920x420x390
