UB 920x420x1377
Universal Beams
refer to : EN 10365:2017
a European standard that defines the dimensions, tolerances, and sectional properties for hot-rolled steel channels, I-beams, and H-beams used in construction and engineering. It ensures uniformity and compatibility across European structural steel products.
Dimension : 1093x473x76.7×115.1
Depth : 1093 mm
Width : 473 mm
Web Thickness : 76.7 mm
Flange Thickness : 115.1 mm
Root Fillet Radius : 19 mm
Sectional Area : 1754 cm2
Unit Weight : 1376.9 kg/m
UB 920x420x1377
