PFC 380x100x54
Parallel Flange Channels
refer to : EN 10365:2017
a European standard that defines the dimensions, tolerances, and sectional properties for hot-rolled steel channels, I-beams, and H-beams used in construction and engineering. It ensures uniformity and compatibility across European structural steel products.
Dimension : 380x100x9.5×17.5
Depth : 380 mm
Width : 100 mm
Web Thickness : 9.5 mm
Flange Thickness : 17.5 mm
Root Fillet Radius : 15 mm
Sectional Area : 68.7 cm2
Unit Weight : 53.9 kg/m
PFC 380x100x54
